230mm LENGTH E-STORIA'S ARE CURRENTLY OUT OF STOCK AND WILL BE IN STOCK FEBRUARY 2025. YOU CAN STILL RESERVE ONE BY ORDERING NOW. also please take a look at other in stock options for this size like the Storia V3-s, Aria and Storia V4
The e-Storia includes the following features:
- Integrated reservoir head design to increase eyelet/trunnion mount fitment
- Stronger body construction
- Chromoly shaft with low friction coating
- Reservoir with large volume bladder design
- Dedicated spring platform to accommodate stiffer springs
- Internal negative spring to avoid harsh top-out and improve bike platform stability
- Lok 2.0
- New rebound adjustment to increase tuning range
- New compression valve design to increase adjustability range and provide more supple low speed characteristics.
- Low hysteresis to improve dynamic response
- Completely independent compression/rebound adjustment
- New check valve with low inertia to control damping even at really high frequency
- New externally adjustable HBC and more efficient design to increase bottom out protection
- New seal design to reduce friction
- New main piston design with high flow to improve sensitivity and tunability
- All valves with turbulent flow to assure consistent damping with different temperature and under extreme use/conditions
- A new high viscosity index oil for longer consistent riding in all different situations and seasons
- Springs available up to 800lb
- Weight 460g (Metric 210x55 without spring)
NOTE: Orders Requiring an HD spring (650lb+) will ship with one spring only. However, an additional HD spring may be purchased for $50.
Product Features
Product Features
Offered in the following Metric/Trunnion eye to eye lengths:
185 (Trunnion)
205 (Trunnion)
210 (Metric)
225 (Trunnion)
230 (Metric)
250 (Metric)
At EXT we have a simple goal: Make the best suspensions to improve performance, reliability and safer riding on any bike.
This isn’t without challenges, E-bikes generate more suspension stress but most run the same shock sizing as their analog counterparts. Luckily, Ext has decades of experience building the world’s most compact high performance dampers, some of which were used in Formula One and WRC. If anyone can maximize damper performance in challenging environments, it’s us.
That’s why we developed the e-Storia.
The bikes we ride and the riders riding them are becoming faster and a lot of that speed is coming from the impressive advances in E-bike technology and the access they have given to a larger group of people. Riders are pushing to new places and making the most of riding from their doorstep. Additionally this new generation of E-bike is appearing, they’re lighter and have longer travel, making their leverage ratios and suspension curves push beyond the boundaries of many current damper designs.
Fitment and Sizing
Fitment and Sizing
For installation tutorial videos, please see our page MTB Installation Videos or visit this LINK.
NOTICE: All dampers should be test fit to the frame and cycled though the travel to ensure frame compatibility and clearance. This is especially important when using aftermarket parts that modify stock geometry or linkage characteristics. We are not responsible for damage to frames where the shock fitment was not initially verified.
Bikes with Known Fitment Issues
- 2020-2023 Specialized Enduro
- 2021-22 Norco Range
- 2020 Specialized Stumpjumper (non EVO model)
- Intense Tazer
- 2019-2022 Specialized Demo
- Trek Rail (Will work with e-Storia)
- Evil Following V3
- Evil Offering V1
- Santa Cruz Hightower (All Versions)
