EXT Storia V4

$1,070.00 USD

Sale Sold out

Shipping calculated at checkout.

Key Features:

4 way adjustable (LSC-HSC-LSR-Lok 2.0 proprietary system)
Unique patent pending PSR hydraulic top out technology to avoid harsh top-out while improving bike platform stability and predictability
Adjustable Hydraulic Bottom-out Circuit (HBC) Technology: our end stroke damping technology that has revolutionized the MTB damper market has been refined even further ensures predictable end-stroke characteristics to allow the user full utilization of travel of the bike while virtually eliminating harsh rebound effects.
Introduction of more commonly found 5mm Allen wrench adjuster for high compression valve vs. the previous 12mm wrench adjuster
LOK 2.0: optimized for pedaling but perfectly at home on every trail section due to an integrated threshold by-pass circuit.
High turbulence flow valves provide a balanced and controlled damping profile while simultaneously minimizing risk of cavitation
Ø14 mm chromoly shaft utilizing diamond like carbon (DLC) coating via physical vapor deposition (PVD) provides state of the art ultra-low friction properties and increased durability from impacts and wear
Tapered Spring Thrust Bushings to improve straight alignment in case of spring side-load conditions
Large volume reservoir using a bladder design and very low reservoir pressure (55PSI) ensures maximum sensitivity
High viscosity index oil provides consistency through even the most tortuous of conditions
30% lighter steel spring, designed from motorsport and tested to perform over 500,000 cycles
Designed for Enduro / Trail riding
Price is for damper only. Springs are available on the product page and a 2nd spring can be purchased at a discounted rate.

Product Features

All Metric Sizes Available (Standard or Trunnion mount)

Eye to Eye Length Stroke
210 or 185 Trunnion 47.5
210 or 185 Trunnion 50
210 or 185 Trunnion 52.5
210 or 185 Trunnion 55
230 or 205 Trunnion 57.5
230 or 205 Trunnion 60
230 or 205 Trunnion 62.5
230 or 205 Trunnion 65

Adding to an already legendary resume the newest iteration of the Storia line of shocks pulls no punches. This shock is designed to further raise the bar on what is possible for performance in MTB damper technology. The overall packaging looks similar to it's predecessor but what lurks beneath the surface is truly revolutionary.

Fitment and Sizing

For installation tutorial videos, please see our page MTB Installation Videos or visit this LINK.

NOTICE: All dampers should be test fit to the frame and cycled though the travel to ensure frame compatibility and clearance. This is especially important when using aftermarket parts that modify stock geometry or linkage characteristics. We are not responsible for damage to frames where the shock fitment was not initially verified.

Bikes with Known Fitment Issues

2021-22 Norco Range
2020 Specialized Stumpjumper (non EVO model)
Intense Tazer
2019-2022 Specialized Demo
Trek Rail (Will work with e-Storia)
Evil Following V3
Evil Offering V1
Santa Cruz Hightower (All Versions)
